Soft Tube automatic filling and sealing machine

This product is a high-tech equipment that was successfully designed and developed by our company after introducing it from abroad and combining it with GMP requirements.

It has the characteristics of reasonable structure, integrated functions, convenient operation, accurate loading volume, stable operation and low noise.

The PLC programmable controller is used to program the operation of the whole machine,

and the processes from liquid to high-viscosity fluid materials (paste) to filling and sealing to coding batch numbers (including production date) are fully automated.

It is an ideal equipment for filling and sealing aluminum tubes, plastic tubes, composite tubes in cosmetics, pharmaceuticals, food, adhesives and other industries, and complies with GMP specifications.

Product Feature:

Hoses material: metal pipe, aluminum pipe, plastic pipe, composite pipe

Hose diameter: Φ10- Φ42

Hose length: 50-250 (can be customized)

Filling capacity: 5-500ml/tube (adjustable)

Filling accuracy: ≤±0.5% ≤±0.5%

Speed(r/min): 3-10 2.5-7

Production capacity (pieces/minute): 30-60

Compressed air: 0.55-0.65mpa

Motor power: 2kw (380V/220V 50Hz)

Heat sealing power: 3kw

Overall dimensions: 2500×1020 ×1980 mm

Host weight (kg): 1100kg

The filling production line integrated production expert around you

Tengzhuo was founded in 2011 and has more than ten years of experience in the packaging equipment industry. Design the filling production line according to your requirements and workshop layout.

Our products include: filling production lines, bottle washing machines, filling machines, capping machines, labeling machines, sleeve labeling machines, cartoon palletizing machines, etc.

The main electrical components are all from international brands, such as PLC and touch screen from Siemens, servo from Panasonic or Schneider, cylinder from Airtac, and power switch from Schneider. Each piece of stainless steel is made of thick 304 material and will never rust.

The products have passed CE certification.

Our company has 16 senior engineers and designers, 5 CNC lathes and milling machines, and more than 10 other professional production machines and equipment. We have truly integrated R&D, design, processing, assembly, installation and debugging to meet all your pre-sales, installation, production and after-sales problems.
