1000PCS/Hour Automatic Weighing Filling Machine For Manufacturing Plant

Ask Lasest Price
Brand Name :	TZ
Price :	directly factory price offer
Payment Terms :	T/T, Western Union, MoneyGram
Delivery Time :	7-55 work days.

Add to Cart

Product Details
Company Profile

1000PCS/Hour Automatic Weighing Filling Machine For Manufacturing Plant

Easy To Operate Automatic Weighing Filling Machine For Manufacturing Plant

Automatic weighing filling machine

weighing filling machine is suitable for liquid filling of 4-20L various barrel types. It has flexible filling method, fast filling speed, accurate measurement and good stability, and is not affected by the viscosity and temperature of oil. It is suitable for oil, fluid, pesticide, lubricating oil, edible oil, engine oil, paint, foliar fertilizer and other materials. It has a fast filling speed and is suitable for filling small and medium-sized packaging of small and medium-sized production enterprises.

Product Description:

1. Imported sensors, stable use, long life;
2. Computer automatic control weighing, high precision;
3. Side irrigation edge lift to ensure the filling accuracy;
4. Vacuum pumping system, to ensure that no drip;
5. Automatic socket function, save time, labor;
6. After special treatment, high temperature liquid, corrosive liquid, high viscosity liquid can be filled.

Product Paramenters

Parameters of Turn Table
Suitable bottles	According to customer samples
Turn table diameter	900mm, H: 750mm
Power	220V, 140W, 50HZ, single phase

Parameters of Multiple Weigh Filler
Each time weigh range	10-1000g
Max weigh weight	6500g
Average bag error	0.2-0.7g
Weigh precision	0.1-1.5g
Max weigh speed	1200BPH (1000g)
Tank	Twin row no memory tank, volume: 2500ml
Driven	Stepping motor
Products preset 99 groups
Multiple weigh quantity	14
Filling quantity	1

Parameters of Chuck Type Filling Machine
SFilling nozzle quantit	1
Suitable bottles	According to customer samples
Filling volume	According to customer samples
Filling capacity	30BPM
Power	220V, 1.5KW, 50/60HZ, single phase
Air pressure	0.6-0.8MPa

Parameters of Desiccant Parcel Delivery Machine
Desiccant parcel size	15-30*40-60mm
Capacity	30BPM
Power	220V, 50H
Dimension	6506501360mm
Machine weight	100kg

Parameters of Chuck Type Can Sealing Machine
Suitable products	According to customer samples
Cap feeding way	Pneumatic feeding
Can sealing way	Single head claw type sealing
Capacity	30BPM
Main motor	370W

Parameters of Automatic Screw Capping Machine
Cap distributor way	Lift
Suitable products	According to customer samples
Capacity	30BPM
Power	800W

Parameters of Vertical Round Bottle Labeling Machine
Suitable products	According to customer samples
Label position	Cycle of the round bottle
Label precision	±1
Capacity	30BPM
Power	220V, 800W

Technical parameters:

Filling heads: 4 6 8 (based on your requirements)
Filling Weight: 5-30kg
Power supply: 220±10%
Production speed: 50-1000 barrels/hour
Power: 2.5KW
Import Pressure: 0.2-0.25mpa
Accuracy: ≤0.3%

Main Functions

1. The machine uses microcomputer control, the calculation is more accurate and faster.
2. Using double shock absorber structure, running more stable, low noise.
3. Small size, the appearance of more beautiful
4. Using stainless steel, does not contaminate raw materials
5. Low energy consumption, low power, more environmentally friendly
